3 Isigaba se-MCB Breaker
Model:DAB2-63
Khetha i-CDADA njengomkhiqizi nomnikezeli wakho wempahla, futhi uthole i-MCB Breaker yethu Yezigaba ezi-3, i-CE CB CCC egunyazwe amandla okuphuka angu-6kA okusabalalisa amandla ezimbonini nawezohwebo. Lo mkhiqizo usebenzisa igobolondo elinganqamuki ilangabi kanye nokugibela okunemba kwe-thermal-magnetic, kulula ukukhwezwa kumzila wesitimela we-DIN futhi kulula ukuwunakekela. Ihlanganisa ukusebenza okuzinzile nempilo ende yemishini kanye nekagesi, iqinisekisa ukuvikelwa kwesekethe ephephile yezinhlelo zamandla ezigaba ezintathu.
I-CDADA DAB2-63 3 Phase MCB Breaker iyisihlukanisi sesekethe esincane sekhwalithi ephezulu esidizayinelwe amasistimu okusabalalisa amandla e-AC ezigaba ezintathu. Inikeza ukugcwala okugcwele okugcwele kanye nokuvikelwa kwesekethe esifushane, ngamajika e-B/C/D okukhubeka ukuze afane nemithwalo ehlukene.
Yakhelwe ngezinto ezingabambezeli ilangabi kanye nezingxenye ezinembayo, le MCB yezigaba ezi-3 isetshenziswa kakhulu kumabhodi okusabalalisa, imishini yezimboni, kanye nezinhlelo zikagesi zokwakha.
Izinzuzo Eziyinhloko
★ 3-isigaba compact design, kufanelekile amabhokisi ukusatshalaliswa ejwayelekile
★ 6kA high breaking umthamo for okuthembekile ukuvikelwa short-circuit
★ Visual inkomba window: red ON / green OFF for isimo esicacile
★ Isibambo esibanzi sokusebenza okuzinzile nokuxhumeka okuvikelekile
★ Izinsimbi zokugcina izinqamuleli zokunciphisa ukushisa nokuthuthukisa ukuzinza kwezintambo
★ Isiqeshana sesitimela se-DIN sokukhiya kabili ukuze kufakwe ngokushesha, okuqinile
★ igobolondo flame-retardant, izinga lokushisa eliphezulu ukumelana
★ 100% ukuhlolwa okugcwele kwemboni ngaphambi kokuthunyelwa
Izinhlelo zokusebenza
★ I-CDADA 3 Phase MCB Breaker isetshenziswa kabanzi ku:
★ Amaphaneli okusabalalisa izakhiwo zokuhlala, ezohwebo nezomphakathi
★ Ama-workshops embonini, izimboni, kanye nemishini encane yamandla
★ Amafeni, ama-compressor, amaphampu, imishini yokuphakamisa
★ Amasistimu okukhanyisa, amasokhethi amandla, namasekhethi e-motor ezigaba ezintathu
★ Ingqalasizinda, amagridi kagesi, namaphrojekthi ekhabhinethi kagesi
Imingcele Yezobuchwepheshe
|
Into |
Ukucaciswa |
|
Imodeli |
I-DAB2-63 1P/1P+N/2P/3P/3P+N/4P |
|
Okujwayelekile |
I-IEC60898-1, GB10963.1 |
|
Izitifiketi |
CE, CB, CCC, ASTA |
|
Ukuphula Amandla |
4.5kA, 6kA |
|
Ikalwe okwamanje |
1A, 2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
|
Ijika Elijikayo |
B(3-5In), C(5-10In), D(10-20In) |
|
I-Voltage elinganiselwe |
400/415V AC |
|
I-Insulation Voltage |
500V AC |
|
Impulse Voltage |
4kV |
|
Idigri Yokuvikela |
IP20 |
|
Ukufakwa |
35mm DIN ujantshi |
|
Impilo Yemishini |
20,000 imijikelezo |
|
Ukuphila Kagesi |
10,000 imijikelezo |
|
Flame Class |
I-UL94 V0 |
|
I-Ambient Temp |
-25℃ ~ +45℃ |
|
I-Wiring Range |
0.75–35mm² okuqinile / okuhlanganisiwe |
I-Outline Dimensions
★ Ububanzi obujwayelekile: 17.8mm isigxobo ngasinye
★ 3P isamba ububanzi: 53.4mm
★ Ukukhweza: 35mm DIN ujantshi (noma yisiphi isikhundla)
★ I-torque yezintambo: 3.5N · m
★ Isakhiwo esihlangene samakhabethe kagesi ajwayelekile
Ikhwalithi yokulawula
★ ISO9001 uhlelo lokuphathwa kwekhwalithi
★ 90% wezingxenye ezibalulekile ezikhiqizwa endlini
★ 100% ukulinganisa: 1.13Okungelona uhambo, 1.45In uhambo
★ Ukuhlolwa kokugibela kazibuthe (5In / 10In ye-C-curve)
★ Ukuhlolwa kokukhuthazela kokushisa okuphezulu nokuphansi
★ Ukuqinisekiswa kwempilo yokuguga nomshini
Ukupakisha & Ukuthumela
★ Ibhokisi lokuthekelisa elijwayelekile eline-shockproof lining
★ Sula ilebula: imodeli, izigxobo, zamanje, ubuningi, izitifiketi
★ Ukupakishwa kwebhokisi leqembu ukugwema ukuklwebheka nokulimala
★ Ilungele ezokuthutha zasolwandle, emoyeni, nasemhlabeni
★ Ukusekela ukupakishwa kwe-OEM nokulebula ngokwezifiso
Amacala Empumelelo Yekhasimende
★ I-CDADA 3 Phase MCB Breaker inokubambisana kwesikhathi eside namakhasimende omhlaba:
★ Amaphrojekthi wokwakha wezindawo zokuhlala nezohwebo eYurophu, eNingizimu-mpumalanga ye-Asia, eMpumalanga Ephakathi
★ Ukusatshalaliswa kwamandla embonini yezimboni e-Afrika, eNingizimu Melika, e-Asia
★ Ubambiswano lwe-OEM ne-ODM nemikhiqizo kagesi yomhlaba wonke
★ Ukunikezwa kwenqwaba yesikhathi eside kubasabalalisi bamazwe ngamazwe nosonkontileka
★ Isetshenziswa kakhulu kumagridi kagesi, ingqalasizinda, nezihlanganisi zesistimu kagesi
